Corrugated Cardboard Box Creasing Die Cut Cutting Machine Making Corrugated
Corrugated Cardboard Box Creasing Die Cut Cutting Machine Making Corrugated indenting and
embossed/depressed cold-pressing of paper boxes, cartons or trademarks of package & decoration industries.
The state-of-the-art structures such as pneumatic clutch and pneumatic locking plate are used for this machine
in addition to automatization for paper feeding, die cutting, paper collection, counting, man-machine interface and
inspection. The production can be lasted continuously, improving the efficiency. This machine features easy / quick
operation, safe, high pressure, high precision and good quality etc.
*Easy to deal with mass production continuously.
*Quick-lock version frame device, shorten the debugging time by 50%.
*With center alignment function from conveying to die cutting.
*Automatic pressure adjustment system by servo motor, higher precision and more convenient.
*Automatically decrease pressure if no paper, extend mould service life.
*Non-stop sampling function, improve work efficiency.
|
Models &Parameters
|
SC1300
|
SC1500
|
SC1650
|
|
Max Paper Size
|
1320*980mm
|
1510*1120mm
|
1670*1200mm
|
|
Min Paper Size
|
350*450mm |
450*500mm |
500*550mm |
|
Max Die Cutting Size
|
1300*960mm |
1490*1100mm |
1650*1180mm |
|
Die Cutting Pressure
|
350T |
380T |
400T |
|
Corrugated Paper
|
3-10mm |
3-10mm |
3-10mm |
|
Max Die Cutting Speed
|
5000(pcs/h) |
5000(pcs/h) |
4500(pcs/h) |
|
Total Power
|
24.5KW |
24.5KW |
32KW |
| |
Stripping 28.5KW |
Stripping 28.5KW |
Stripping 35KW |
|
Total Weight
|
16.5T |
19.5T |
23T |
| |
Stripping 18.5T |
Stripping 21.5T |
Stripping 26T |
|
Whole Size(mm)
|
5900*2365*2346 |
6200*2380*2356 |
7000*2980*2450 |
| |
Stripping 7080*2365*2346 |
Stripping 7400*2365*2346 |
Stripping 8500*2365*2346 |
Vaccum feeding unit:
1, The newest servo-drive and vacuum suction belt feeding system
2, Suitable for all kinds of paper, and data setting can be adjusted on the touch screen.
3, Big size front and side baffles make cardboard at right position, providing high die-cutting precision.
4, Paper leveling device is specially designed for bent cardboard, stopping cardboard cover the front baffle.
Die cutting unit:
1, Steady die-cutting performance & Strong and reliable high speed driven
2, Die-cutting frame locking structure, the die-cutting steel plate is used air reducer to reduce the weight, easy control.
3, Die-cutting positioning device can reach quick locating and higher accuracy of die-cutting.
4, ASAHI spike gripper is specially designed for the heavy warping board, stable and durable
|
|
Stripping unit:
1, The quick-setting way of die is adopted; operator can finish the setting from exterior without entering the machine.
2, Male and female die can be inserted into the machine from operation side to shorten the setup time and for higher safety.
3, Upper and lower frames make the dies succeed in performance. Male and female dies can move up-an-down,making stripping more completely.
4, A plastic film is set between die-cutting section and lower frame for stopping paper swerve. It can be adjusted by moving handcrank according to the size on the dies operation direction.
|
|
Features:
√ Exclusively for laminated board and corrugated board with the newest servo-drive feeding system.
√ Accurate die-cutting from E flute to AB flute.
√ Completed stripping is by stripping system and grip edge waste removal device.
√ Excellent adaptability for small and big production.
√ Reliable safety performance and dual safety security device designed. (Air brake and power-off shutdown devices.)
√ All operation is on the exterior of the machine.
√ High Productivity, Precise Die-cutting, Precise Creasing, Smooth Stripping and Convenient Operation.
Q1: How is the warranty of the machine?
A: Warranty period: 12 months from the shipping date of machine. Warranty will be not valid if machine subject to misuse or accidental damage or operator's error. During the valid time, we will supply spare parts. If you have any other questions, Kindly contact us and we will reply you through product's photos and videos to make every detail clear.
Q2: How about the after-sale service?
A: 1) TM online 24 hours, also contact by email, skype, wechat, whatsapp, etc.
2) To solve the problems with videos/pictures.
3) One year warranty for spare parts change.
Q3: Is it safe on the payment for me as we are the first cooperation?
A: We can do the trade assurance on Alibaba, which will guarantee your products receiving, we also accept other safe payment way as you want.
Q4: What is your minimum order quantity, can you send me samples?
A: Our minimum quantity is 1 set, as our product is machinery equipment, it is difficult to send you samples, if you have any questions about the products, please feel free to contact us for more detail, we are glad to provide you more information such as specifications, video, etc.
Adopts moisture-proof and shock-proof packaging which is suitable for long-distance road
transportation and various types of weather conditions. A full set of maintenance and operation
manuals is included.
