Voltage 380V 5 Layer Corrugated Cardboard Production Line With Main Drive Servo Motor 22 KW Providing Output And Consistent Corrugated Board

1 Set
MOQ
To Be Negotiated
Price
Voltage 380V 5 Layer Corrugated Cardboard Production Line With Main Drive Servo Motor 22 KW Providing Output And Consistent Corrugated Board
Features Gallery Product Description Request A Quote
Features
Specifications
Orders: Store 200 Orders
Minimum Cutting Length: 500mm
Cutting Precision: ±1mm
Voltage: 380V
Frame: HT250
Rear Feed Motor: 1.5KW（frequency Control）
Machine Name: NC Cutting Machine
Flute Type: A,C,B,E1,E2,F,G
Highlight:

380V corrugated cardboard production line

,

5 layer servo motor cardboard line

,

22KW corrugated board manufacturing machine
Basic Infomation
Brand Name: Gerun
Certification: CE,ISO
Model Number: 1400/1600/1800/2000/2200/2500
Payment & Shipping Terms
Packaging Details: Plastic,wood
Delivery Time: 20 Days
Payment Terms: T/T
Supply Ability: 100 Sets/year
Product Description
Product Overview
This 380V 5-layer corrugated cardboard production line features a full AC servo control system, energy storage brake, and spiral blade structure with oil-immersed gear mechanism. Equipped with a 10.4-inch touch screen display, it stores up to 200 orders for quick specification changes and supports networked production management.
Key Features
  • Full AC servo control system with energy storage braking
  • 10.4-inch touch screen display for easy operation
  • Stores up to 200 orders for quick specification changes
  • Precision-forged steel cutter shaft with induction hardening
  • Spiral structure combining front steel blade with serrated knife
  • Sun gear pressure plate feeding method prevents sheet crushing
  • Energy-efficient design saves over 70% in electricity costs
  • Independent oil pump and filter system for optimal lubrication
  • High-quality forged steel knife roller for excellent stability
Technical Specifications
ParameterSpecification
Machine TypeNC Cutting Machine
UsageCorrugated Cardboard Cutting
Cutting Precision±1mm
Maximum Cutting Length9999mm
Minimum Cutting Length500mm
Voltage380V
Main Drive Servo Motor22 KW
Forward Motor1.5KW (Frequency Control)
Rear Feed Motor1.5KW (Frequency Control)
Flute TypesA, C, B, E1, E2, F, G
Working Speed150m/min
Knife Axis Material42CrMo
Applications
This versatile production line is ideal for manufacturing single facer production lines and complex 7-layer corrugated cardboard. Suitable for high-volume production environments in electronics, food, pharmaceuticals, and logistics sectors. Available in models 1400, 1600, 1800, 2000, 2200, and 2500 with CE and ISO certification.
Customization Options
Gerun offers customizable production lines for 3, 5, and 7-layer corrugated paperboard sheet production. Working width ranges from 1600mm to 2500mm can be customized. Minimum order quantity is 1 set with 20-day delivery and T/T payment terms.
Support & Services
Comprehensive technical support including installation guidance, maintenance services, troubleshooting, and on-site training. We provide detailed documentation, software updates, mechanical adjustments, and process optimizations to ensure optimal performance.
Packaging & Shipping
Equipment is securely packaged with protective materials and loaded onto sturdy wooden crates. Shipping options include sea, air, or land transport with detailed documentation for smooth customs clearance and installation.
