Computer-control Helical Cross Cutter Corrugated Cardboard Production Line With Highest Machinery Speed 100mmin Double NC Cutter Precision ±1mm

This advanced cutting machine features a computer-controlled helical cross cutter with precision of ±1mm and maximum speed of 100m/min. Capable of storing up to 200 unit orders, it enables quick cutter specification changes without production interruption.

• Network capability for computer-managed production process
• Precision forged steel knife shaft drive gears with induction hardening
• Advanced keyless connection for backlash-free transmission
• Inlaid front steel blade knife with spiral structure and serrated scissors
• Sun gear platen method for smooth material delivery
• Braking energy storage system reducing energy consumption by 70%
• Precision adjustable no-gap gear for balanced running
• Independent oil pump and filter lubrication system
• Fine quality forged steel knife roller for optimal stability

• Distance between knife shaft centers: ￠216mm
• Front lower conveying roller: ￠156mm
• Rear lower conveying roller: ￠156mm
• Front platen roller: ￠70mm
• Rear platen roller: ￠70mm

• Main drive motor: 18.5KW, Full AC synchronous servo
• Front and rear feeding motor: 3KW (Frequency Control)
• Lubricating oil pump motor: 0.25KW

The Gerun Corrugated Cardboard Production Line is designed for efficient manufacturing of 3/5/7 layer corrugated cardboard sheets. Ideal for packaging industry companies producing carton boxes, with models available in 1400, 1600, 1800, 2000, 2200, and 2500 specifications.

Certified by CE and ISO standards, this equipment guarantees high quality and reliability for industrial applications requiring precise cutting with minimum length of 500mm and effective width of 2200mm.

Available in multiple models with flexible voltage options including 220v, 380v, 440v, or custom configurations. Features computer-controlled helical cross cutter with precision cutting uniformity of ±1mm.

Comprehensive support including expert installation guidance, operator training programs, detailed maintenance manuals, troubleshooting assistance, spare parts supply, and system upgrades. Regular software updates and preventive maintenance services to minimize downtime.

Secure packaging with protective materials, sturdy wooden crates or reinforced steel frames. Flexible shipping options including sea freight, air freight, and land transportation with comprehensive tracking. Delivery within 20 days after order confirmation.
