Jumbo Size Corrugated Board Automatic Folder Gluer Machine Whole Computer Adjust

AUTOMATIC FOLDER GLUER MACHINE

Function

GR-QF-W-1 fully automatic folder gluer machine achieve whole computer adjust gluing unit, feeding unit and folding unit, just enter three data on the touch screen, machine can automatic adjust to the exact position.

This machine was also equipped with single computer NC adjustment, it can adjust any section individualy, what is more, the machine also has adjustment button, which can meet different operation requirement.

CHARACTERISTIC

1.PLC program control data adjustment, enter the carton box specification into the touch screen.

2.The wallboard adopt 40mm cast iron material.

3.Feeding unit adopt printing machine model gear transmission,more steady than traditional chain, wheel and chain transmission less noisy and more precision.

MAIN STRUCTURE OF MACHINE

Feeding Section

1.Vacuum suction feeding to feed warping paperboard easily

2.Quality electromagnetic clutch and brake adopted, feeding section controlled independent,operate easily

3.Scorer wheel adjustable, suit for 2-8mm thick paperboard

4.Second creasing construction can impress again the paperboard which was not creased well

Gluing and Folding Section

1.Simpless structure and high reliability, glue quantity adjustable, cleaning easily.

2.Stainless steel glue wheel adopted,long using life and saving glue cost.

3.Imported quality rubber belt adopted,automatic folding.

4.With paperboard rectify device and creasing rectify device.

Counter and Stacker Section

1.Stacking and counting are simple and reliable.

2.Digital control,operation easily and reliable. No-stop put in data and automatic counting.

3.With rectification function.

4.Paperboard counting and put out by pneumatic, stable and quickly.

Technical Parameter:

Our company

 Product packaging

FAQ:
Q1: How is the warranty of the machine?
A: Warranty period: 12 months from the shipping date of machine. Warranty will be not valid if machine subject to misuse or accidental damage or operator's error. During the valid time, we will supply spare parts. If you have any other questions, Kindly contact us and we will reply you through product's photos and videos to make every detail clear.
Q2: How about the after-sale service?
A: 1) TM online 24 hours, also contact by email, skype, wechat, whatsapp, etc.
2) To solve the problems with videos/pictures.
3) One year warranty for spare parts change.
Q3: Is it safe on the payment for me as we are the first cooperation?
A: We can do the trade assurance on Alibaba, which will guarantee your products receiving, we also accept other safe payment way as you want.
Q4: What is your minimum order quantity, can you send me samples?
A: Our minimum quantity is 1 set, as our product is machinery equipment, it is difficult to send you samples, if you have any questions about the products, please feel free to contact us for more detail, we are glad to provide you more information such as specifications, video, etc.
